API 6A FC VALVE GATE FOR CAMERON GATE VALVE

Working Pressure: 2000PSI-20000PSI
Media: oil, gas, water
Port Size:2 1/16"~7 1/16"
Application: well drilling
Material Class:AA-FF
Temperature Class:PU
PSL: OSL1-PSL4
PR: PR1-PR2
2 1/16" ~7 1/16":
Quantity:
  • FC
  • SAIGAO
  • 84306990

API 6A Valve Gate, Forging Valve Gate

Full bore design eliminates efficiently pressure drop and vortex, eliminates washing by solids in fluid.
• Special seal type lower switch torque.
• Mental-to-mental seal is used between bonnet and body, gate and seat rising.
• Mental-to-mental seal between gate and seat, and the surface is weld overly with hard alloy, which has feature of corrosion resistance and washing resistance.
• Retainer plate fix seat ring insuring good stability.
• The stem designed with back seal, can replace stem sealing under pressure.
• One side of bonnet is designed with sealant injection in order to supply sealant and improve seal and lubrication performance of gate and seat.
• Can complete with different pneumatic (hydraulic) actuator upon user’s requirements.


Specifications

API 6A Valve Gate
Material: Inconel 625, Inconel 718, Incoloy 825, duplex S.S, AISI 4130, 17-4PH etc

 API 6A valve gate,  forging valve gate

Main Materials:  Inconel 625, Inconel 718, Incoloy 825, duplex S.S, AISI 4130, 17-4PH etc

Main Manufacturing Process: Forging

Machining: lapping, coating etc can be executed inhouse.

Also, SAIGAO is able to provide you valve seats in Cobalt base alloy (Stellite).
